Description
Sun / Conderenergy 3KVA 3KW 24V Solar Inverter S-2831
Features:
- Pure sine wave solar inverter
- Compatible to AC mains or generator power
- Considerable PV input voltages
- Build-in MPPT solar charger
- Wide DC input range
- Auto restart while AC is recovering
- Overload and short circuit protection
- Cold start function
- Configurable AC/Solar input priority via LCD setting
- Selectable input voltage range for home
appliances and personal computers
Specifications:
- PV INPUT:
- Max. PV Array Open Circuit Voltage 145Vdc
- PV Array MPPT Voltage Range 30Vdc~115Vdc
- Max. PV Array Power
- PV1 Channel 1500W
- GRID/AC OUTPUT:
- Nominal Output Voltage: 208/220/230/240Vac
- Power Factor: 1
- Nominal Operating Frequency: 50/60Hz
Svolt 24V 106AH 2.71 KWH A-GRADE LITHIUM BATTERY WITHOUT COMMS CNN2511 (XEA25A) Lithium-ion Battery
Specifications:
Battery Type: LiFePO4 (Lithium Iron Phosphate)
Nominal Voltage: 25.6V
Nominal Capacity: 106Ah
Energy: 2.71 kWh (2713.6 Wh)
Internal Resistance: < 25 mΩ
Dimensions (L x W x H): 419 x 350 x 154 mm
Weight: 25.4 kg
Energy Density: 2713.6 Wh
Case Material: SPCC (Steel Plate Cold Coil)
Terminal Type: Feed-through Terminal
BMS Built-in: Yes
What’s in the box:
- 1 x SVOLT 24V 106Ah A-Grade Lithium Battery
- 1 x Red (Positive) Battery Cable
- 1 x Black (Negative) Battery Cable
- 1 x Ethernet cable
- 1 x Manual
Combo Includes:
1x S-VOLT 25.6v 106ah Lithium LifePO4 2.71Kwh (5 Years Warranty)
1x Hybrid Inverter 3kva Conderenergy (2 Years Warranty)
3x Tier 1 Solar 450w Megatron Solar Panel (12 years warranty)
PLEASE NOTE COURIER FOR SOLAR PANELS ARE AT YOUR OWN RISK
Warranties:
All inverters and batteries must be installed by a qualified electrical wireman or Master electrician with a valid registration with the Department of Labour. A valid electrical certificate of compliance (COC) must be issued once installed, specific to the installation of the backup or solar system. The installation must be compliant with SANS 10142 and ALL its parts. Any warranty claim submitted without installation photos, a valid COC and proof of a qualified wireman/master electrician installing the unit, can be rejected and will render the warranty claim null at void.
