Description
Hybrid Inverter 24v 3.5 Kva 3500w MPPT 100A Inverter Pure Sine Wave – Ecco
Model Name : HIN3500L
Inverter Mode :
Rated Power : 3500VA/3500W
DC Input : 24VDC 158A
AC Ouput : 230VAC 50/60Hz 15.2A
Ac Charger Mode :
AC Input : 230VAC 50/60 Hz 23.5A
DC Ouput : 27VDC
MAX Charge CUrrent : 80A
Max Charger Current AC+PV : 100A
AC Ouptu : 230vac 50/60 hz 15.2A
Solar Charger Mode:
Max PV Array Power: 4000W
Min Solar Voltage : 60VDC
Max Solar Voltage (VOC) : 500VDC
Max Charge Current : 100A
Ritar 25.6v 100ah Lithium LifePO4 2.56Kwh
SAFETY
+ Prismatic LFePO4 cells, Longer cycle life and much more safety.
+ Low voltage system, safety for application.
+ IEC62619, UI1973 certification for cell.
UN38.3, MSDS certification for system.
DESIGN
Standard 19″ rack design, support rack or wall mounted.
Flexible and easily installation.
+ -20~+55C widely temperature range.
+ Maintenance free.
BATTERY MANAGEMENT SYSTEM (BMS)
+ Independent protection for charge and discharge.
+ Over charge protection, over discharge protection and over temperature, short circuit protection.
| Nominal voltage [V] | 25.6 |
| Nominal capacity [Ah] | 100 |
| Total energy [kWh] | 2.56 |
| Max. charging current [A] | 100 |
| Max. charging Voltage [V] | 29.2 |
| Charging voltage [V] | 27.6-28.8 |
| Max. discharging current [A] | 100 |
| End of discharge voltage [V] Product dimension [W*D*H] | 442*300*110 |
| Product weight [kg] | 23 |
| Protection class | IP20 |
| Operating humidity | 0-95% RH (No condensing) |
| Operating temperature range Communication interface | Standard Product: Charge: 0 ~ +55C; Discharge: -20 ~ +55C |
| Cycle Life | 6000 |
| Protection | OVP, LVP, OCP, OTP, LTP protection. |
| Certification | UN38.3, MSDS, CE |
| Series Support | No support |
| Parallel Support | Yes, Max 15pcs |
Combo Includes:
1x Ritar 25.6v 100ah Lithium LifePO4 2.56Kwh (5 Years Warranty)
1x Hybrid Inverter 3.5kva Ecco (3 Years Warranty)
3x Tier 1 Solar 450w Megatron Solar Panel (12 years warranty)
PLEASE NOTE COURIER FOR SOLAR PANELS ARE AT YOUR OWN RISK
Warranties:
All inverters and batteries must be installed by a qualified electrical wireman or Master electrician with a valid registration with the Department of Labour. A valid electrical certificate of compliance (COC) must be issued once installed, specific to the installation of the backup or solar system. The installation must be compliant with SANS 10142 and ALL its parts. Any warranty claim submitted without installation photos, a valid COC and proof of a qualified wireman/master electrician installing the unit, can be rejected and will render the warranty claim null at void.
